IEK
SKU: PSR02-016-5-6-67
ETIM: EC000140
1305 ₽
Price list (incl. VAT):
1727 ₽
Available August 24
Order multiple: 10
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
1439 | шт | August 24 | clarifying |
Select a warehouse to order
No description available
| Military grade | No |
| Operating voltage range | 200...415 |
| Cable entry | Sealing nut |
| Number of poles | 5 |
| Maximum current | 16 А |
| Maximum conductor cross-section | 2.5 кв.мм |
| Marking color | Red |
| Material | Plastic |
| Housing material | Plastic |
| With interlock | Without interlock |
| Voltage in accordance with EN 60309-2 and colour | 380-415 V (50+60 Hz) red (*) |
| Rated frequency | 50/60 |
| Rated dielectric strength of insulation | 690 |
| Rated voltage | 380 В |
| Key position in clock hours | 6 ч |
| Connection method | Screw terminal |
| IP protection rating | IP67 |
| Operating temperature from | -25...40 град.C |
| Connection angle | Str./straight |
| Phase inverter | Yes |
| Locking device | Bayonet ring |
| Number of contacts | 3P+N+PE (three-phase 5-conductor) |
