Portable plug SSI-0242 32A 6p 380V 3P+PE IP67 IEK PSR02-032-4-0-67
SKU: PSR02-032-4-0-67
ETIM: EC000140
12,510 ₽
Get back 125 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 10 шт
Analogues by specifications
Stock by warehouse
IP67 rated power connectors are used indoors where there is a risk of moisture and dust exposure, and outdoors in conjunction with mobile electrical equipment with cable power systems and stationary single-phase and three-phase electrical equipment. They are designed for connecting construction electrical equipment and power tools, power supply for temporary structures and cabins, machines and other industrial equipment, power supply for sports facilities and cultural mass event venues, hotels, tourist bases, etc.
Military grade
No
Operating voltage range
380...415
Cable entry
Sealing nut
Number of poles
4
Maximum current
32 А
Maximum conductor cross-section
6.0 кв.мм
Marking color
Red
Material
Plastic
Housing material
Plastic
With interlock
Without interlock
Voltage in accordance with EN 60309-2 and colour
380-415 V (50+60 Hz) red (*)
Rated frequency
50/60
Rated dielectric strength of insulation
690
Rated voltage
380 В
Key position in clock hours
6 ч
Connection method
Screw terminal
IP protection rating
IP67
Operating temperature from
-25...40 град.C
Connection angle
Str./straight
Phase inverter
No
Locking device
Bayonet ring
Number of contacts
3P+PE (three-phase, 4 conductors)
