IEK
MAGNUM Fixed Plug SSI-513 16A-6h/200-250V 2P+PE IP44 IEK PSN51-016-3
SKU: PSN51-016-3
ETIM: EC000140
1432 ₽
Price list (incl. VAT):
1627 ₽
Available August 20
Order multiple: 10
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
940 | шт | August 20 | August 20 |
Select a warehouse to order
The original design of MAGNUM power connectors was developed by IEK engineers in strict accordance with international and Russian standards and taking into account the wishes of consumers - professional electricians and installers. The design solution of MAGNUM power connectors combines the best world experience with a number of specialized unique developments by IEK engineers.
Progressive design solutions combined with the use of high-quality materials and a high level of production quality guarantee high reliability and safety of the design, ergonomics and environmental friendliness of the products, and maximum convenience of installation and removal of MAGNUM power connectors.
MAGNUM power connectors are suitable for connecting construction electrical equipment and power tools, power supply for temporary structures and cabins, machines and other industrial equipment, for power supply of sports facilities and cultural mass event venues, hotels, tourist bases, etc.
MAGNUM IEK power connectors are manufactured in Russia, at the main production site of IEK Group.
| Military grade | No |
| Operating voltage range | 200-250 |
| Cable entry | Sealing nut |
| Number of poles | 3 |
| Maximum current | 16 А |
| Maximum conductor cross-section | 2.5 кв.мм |
| Marking color | Blue/light blue |
| Material | Plastic |
| Housing material | Plastic |
| With interlock | Without interlock |
| Voltage in accordance with EN 60309-2 and colour | 230 V 50-60 Hz, blue |
| Voltage from | 220 В |
| Rated frequency | 50/60 |
| Rated dielectric strength of insulation | 500 |
| Rated voltage | 220 В |
| Key position in clock hours | 6 ч |
| Connection method | Screw terminal |
| IP protection rating | IP44 |
| Operating temperature from | -25...40 град.C |
| Design type | Surface-mount plug |
| Connection angle | Inclined/bevelled/angled |
| Phase inverter | No |
| Locking device | Protrusion |
| Number of contacts | 2P+PE (single-phase, 3 conductors) |
