Generica (Группа IEK)
Twisted pair U/UTP Cat.5E 24AWG 4 pairs PVCLS нг(А)-LSLTx 1m white RF/T GENERICA BC1-C5E04-128-305-T-R-G
SKU: BC1-C5E04-128-305-T-R-G
ETIM: EC003249
124 ₽
Get back 1 ₽ in points
Analogues by specifications
Stock by warehouse
No description available
Cable outer diameter
5
Wave impedance
100 Ом
Conductor diameter
0.48 мм
Cable length
305 м
For laying in the ground
No
Permissible operating temperature (without movement) from
-50...70 град.C
NVP value
69 %
Core insulation
Solid polyethylene
Category
5E
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
P1b.8.2.1.2
Number of cores
8
Number of twisted elements
4
Max mutual capacitance per 100 metres
5.6
Max. contact resistance
20
Max. capacitance unbalance pF per 100 m
160
Max DC resistance per 100m at 20°C, not more than
11.5
Cable/wire grade
U/UTP
Core marking
Colour
Outer sheath material
Other
Conductor material
Copper
Mounting temperature from
-30...70 град.C
Rated transmission rate
69
Rated voltage from
≤ 48 В
Rated conductor cross-section
0.18 кв.мм
Core cross-section
24 мм
Insulation resistance
5000
Operating temperature from
-50...70 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
White
Signal frequency
100
Screen over the twist
No
Screen over stranding element
No
Dielectric strength
1000
Twisting element
Paired
