Fortisflex
Cable gland for flexible metal conduit, stainless steel VK-M32(16-25 mm)-MR32 (INOX) 88171 Fortisflex
SKU: 88171
ETIM: EC000441
Price on request
Order multiple: 4 шт
Analogues by specifications
• For hermetic cable and wire entry/exit in flexible metal conduit within electrical switchgear enclosures
• Material:
• nut, body, locknut: AISI 304 stainless steel
• clamping insert: nylon 6.6, self-extinguishing per UL94V2
• sealing insert and rings: neoprene
• Operating temperature: from -40 °C to +100 °C, short-term +120 °C
• Protection degree IP68
• Thread type: metric per EN 60423 2 in 1: cable gland and conduit connector in one product
• Resistant to synthetic oils and all types of fuel
• Possess special strength, durability, and resistance to aggressive environmental impacts
• Hole mounting tools:
• hydraulic systems for punching holes:
• PGPO-60
• PGPO-60A
• PGPO-115
• hydraulic presses for punching holes:
• PGRO-60A
• PGROu-60A
• PGROp-60A
• PGAPO-60A
• MPO dies for punching round holes, perfom sets: NMPO-PG, NMPO-MG
Supplied with lamp
Yes
Material type/grade
Stainless steel (V2A)
External part height
13 mm
For gas explosion hazardous areas
No (without)
For cable diameter to
25 mm
For cable diameter from
16 mm
For dust explosion protection zone (EU ATEX directives)
No (without)
Kink protection
No
Design
Straight
Lens design
High
Flat cable gland
No
Lens design
Round
Material
Metal
Front ring material
Plastic
Halogen-free
Yes
Rated operating voltage Ue up to
30 V
Rated operating voltage Ue from
16 V
Nominal metric/PG thread size
32
Current type
Direct current (DC)
IP protection rating
IP68
Operating temperature to
100 °C
Operating temperature from
-40 °C
Connection type
Screw connection
Thread type
Metric
Sealing type
Sealing ring (gasket)
Color
Nickel
Lens color
Red
Thread pitch
1.5 mm
EMC-compatible version
Yes
