Plastic cable entry PG 7 (3-6.5 mm) 88639 Fortisflex
SKU: 88639
ETIM: EC000441
11 ₽
Available August 6
Order multiple: 100
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
2100 | pcs | August 6 | August 6 |
Select a warehouse to order
• Designed for the hermetic entry and exit of cables and wires in switchgear enclosures
• Enclosure material: nylon 6.6, flame-retardant, halogen-free per UL94V2
• Sealing material: neoprene
• Color: black
• Operating temperature: from -40 °C to +100 °C, briefly +120 °C
• Thread type: PG- electrical according to DIN 40430
• The compression nut design features special locking notches to prevent self-loosening
• IP 68 protection rating
• Resistant to synthetic oils and all types of fuel
• Wrench size marking on the fastening nut
• Protective membrane prevents dust ingress
• Recommended tools:
• hydraulic hole punching systems:
• PGPO-60
• PGPO-60A
• hydraulic hole punching presses:
• PGRO-60A
• PGROu-60A
• PGROp-60A
• NMPO-PG die set for mounting PG series cable entries
| Material type/grade | Polyamide (PA) |
| For gas explosion hazardous areas | No (without) |
| For cable diameter to | 6.5 мм |
| For cable diameter from | 3 мм |
| For dust explosion protection zone (EU ATEX directives) | No (without) |
| Kink protection | No |
| Design | Straight |
| Flat cable gland | No |
| Material | Plastic |
| Halogen-free | Yes |
| Nominal metric/PG thread size | 0 |
| IP protection rating | IP68 |
| Operating temperature to | 100 град.C |
| Operating temperature from | -40 град.C |
| Thread type | PG |
| Sealing type | Sealing ring (gasket) |
| Color | Black |
| Thread pitch | 1.5 мм |
