Legrand (группа IEK)

Reverse switch-disconnector. DCX-M, 800 A 3P, frame size 4

SKU: 431110

ETIM: EC000216

100175 ₽

Available August 25

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	13	шт	August 25	clarifying

Select a warehouse to order

Description Specifications Reviews

Version as switch-disconnector	Yes
Version as main switch	Yes
Number of auxiliary NO contacts	2
Number of auxiliary changeover contacts	0
Number of auxiliary break contacts	2
Number of poles	3
Design	Built-in fixed-mounted device
Maximum rated operational voltage Ue AC	1000 В
Motor drive optional	No
Independent trip unit	No
Rated power in AC-23 operating mode, 400 V	315 кВт
Rated power at AC-3, 400 V	0 кВт
Rated voltage at	1000 В
Rated voltage from	400 В
Rated short-time withstand current Icw	13 кА
Rated continuous current Iu	800 А
Reversing design	Yes
With interlock	No
Ingress protection (IP) of front side	IP2X
Main electrical circuit connection type	Bolted connection
Control element type	Extended rotary handle
Conditional rated short-circuit current Iq	20 кА
Colour of control elements	Black
