Контактор (группа IEK)
Circuit breaker VA55-41-344750-00UHL3 1000A withdrawable MRT2-MP HP220AC rear copper busbar Contactor 1002530
SKU: 1002530
ETIM: EC000228
2,135,805 ₽
Get back 21,358 ₽ in points
Order multiple: 10 шт
Analogues by specifications
Stock by warehouse
No description available
Main circuit connection type
Rear connection
Built-in ground fault protection
No
Built-in motor drive
No
Height
430.0 мм
Depth
540.0 мм
Short-time delayed short-circuit release range
450…12000 А
Overload protection device setting range to
1000 А
Setting range of overload protection device from
300…1000 А
Instantaneous short-circuit release setting range to
12000 А
Instantaneous short-circuit release setting range from
600…12000 А
Version
Withdrawable
Design
Withdrawable
Number of auxiliary NO contacts
3
Number of auxiliary break contacts
4
Number of poles
3
Design
Slot-in device (withdrawable)
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
41.25
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
55 кА
Rated voltage up to
690 В
Rated voltage from
0...690 В
Rated current
1000 А
Rated continuous current Iu
1000 А
Suitable for DIN-rail mounting
No
Power loss
348 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Extended rotary handle (wide grip)
Width
440.0 мм
