Контактор (группа IEK)
Circuit breaker A3794БУХЛ3 Output El/Mag 630A 690V 6300A PE220-240AC HP110-440AC VK1Z1R VKC2Z2R rear connection copper bus IP00 Contactor 1013827
SKU: 1013827
ETIM: EC000228
356,597 ₽
Get back 3,565 ₽ in points
Analogues by specifications
No description available
Main circuit connection type
Rear connection
Built-in ground fault protection
Yes
Built-in motor drive
Yes
Height
435.0 мм
Height
435.0 мм
Depth
495.0 мм
Short-time delayed short-circuit release range
283.5…7560 А
Overload protection device setting range to
630 А
Setting range of overload protection device from
189…630 А
Instantaneous short-circuit release setting range to
7560 А
Instantaneous short-circuit release setting range from
378…7560 А
Design
Withdrawable
Version
Withdrawable
Number of auxiliary NO contacts
3
Number of auxiliary break contacts
3
Number of poles
3
Design
Slot-in device (withdrawable)
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
50.5
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
51 кА
Rated voltage up to
690 В
Rated voltage from
0...690 В
Rated current
630 А
Rated continuous current Iu
630 А
Suitable for DIN-rail mounting
No
Power loss
195 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Lever (toggle)
Width
435.0 мм
