EKF
Circuit breaker AV-10 2P 63A (B) 10kA EKF AVERES mcb10-2-63B-av
SKU: mcb10-2-63B-av
ETIM: EC000042
154,260 ₽
Get back 1,542 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 60 шт
Analogues by specifications
Stock by warehouse
AV-10 AVERES series circuit breakers are designed for the operational control of electrical circuit sections, as well as for protection against overload and short-circuit currents in administrative, industrial, and residential buildings. AV-10 AVERES series circuit breakers have a rated breaking capacity Icn 10 kA. Warranty obligations are 10 years.
Additional equipment possible
Yes
Mounting installation depth
74 мм
For flush mounting
Yes
Overvoltage category
3
Current limiting class
3
Number of protected poles
2
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
10 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
5.8 кА
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V
10 кА
Rated breaking capacity in accordance with EN 60898
10 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
63 А
Total number of poles
2
Ambient operating temperature to
60 град.C
Ambient operating temperature from
-40...60 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
1...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1...25 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Tripping characteristic
B
Frequency
50 Гц
Frequency at
60 Гц
Frequency from
50...60 Гц
Width in modular units
2
