Circuit breaker AV-10 3P 20A (D) 10kA EKF AVERES mcb10-3-20D-av
SKU: mcb10-3-20D-av
ETIM: EC000042
5887 ₽
Price list (incl. VAT):
11039 ₽
Available August 11
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Manufacturer warehouse | |||||
|
Manufacturer warehouse
Available
|
535 | шт | August 11 | clarifying | |
Select a warehouse to order
AV-10 AVERES series circuit breakers are designed for the operational control of electrical circuit sections, as well as for protection against overload and short-circuit currents in administrative, industrial, and residential buildings. AV-10 AVERES series circuit breakers have a rated breaking capacity Icn 10 kA. Warranty obligations are 10 years.
| Additional equipment possible | Yes |
| Mounting installation depth | 74 мм |
| For flush mounting | Yes |
| Overvoltage category | 3 |
| Current limiting class | 3 |
| Number of protected poles | 3 |
| Rated short-circuit breaking capacity Icu IEC 60898 at 230 V | 10 кА |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 10 кА |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V | 10 кА |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 10 кА |
| Rated breaking capacity in accordance with EN 60898 | 10 кА |
| Rated impulse voltage | 6 кВ |
| Rated voltage | 400 В |
| Rated insulation voltage Ui | 500 В |
| Rated current | 20 А |
| Total number of poles | 3 |
| Ambient operating temperature to | 60 град.C |
| Ambient operating temperature from | -40...60 град.C |
| Current type | AC (alternating) |
| With switched neutral conductor | No |
| Flexible stranded conductor cross-section up to | 16 кв.мм |
| Stranded flexible conductor cross-section from | 1...16 кв.мм |
| Solid conductor cross-section to | 25 кв.мм |
| Solid conductor cross-section from | 1...25 кв.мм |
| Pollution degree (number) | 2 |
| IP protection rating | IP20 |
| Tripping characteristic | It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Frequency | 50 Гц |
| Frequency at | 60 Гц |
| Frequency from | 50...60 Гц |
| Width in modular units | 3 |
