Circuit breaker AV-6 DC 1P 1A (C) 6kA EKF AVERES mcb6-DC-1-01C-av

SKU: mcb6-DC-1-01C-av

ETIM: EC000042

1715 ₽

Price list (incl. VAT): 3216 ₽

Preorder

Description Specifications Reviews

Additional equipment possible	Yes
Mounting installation depth	74 мм
For flush mounting	Yes
Overvoltage category	3
Current limiting class	3
Number of protected poles	1
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V	6 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V	3.5 кА
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V	6 кА
Rated breaking capacity in accordance with EN 60898	6 кА
Rated impulse voltage	6 кВ
Rated voltage	250 В
Rated insulation voltage Ui	500 В
Rated current	1 А
Total number of poles	1
Ambient operating temperature to	60 град.C
Ambient operating temperature from	-40...60 град.C
Current type	DC (direct)
With switched neutral conductor	No
Flexible stranded conductor cross-section up to	16 кв.мм
Stranded flexible conductor cross-section from	1...16 кв.мм
Solid conductor cross-section to	25 кв.мм
Solid conductor cross-section from	1...25 кв.мм
Pollution degree (number)	2
IP protection rating	IP20
Tripping characteristic	C
Frequency	50 Гц
Frequency at	50 Гц
Frequency from	50 Гц
Width in modular units	1
