EKF
Circuit breaker AV-6 DC 3P 6A (K) 6kA EKF AVERES mcb6-DC-3-06K-av
SKU: mcb6-DC-3-06K-av
ETIM: EC000042
7,291 ₽
Get back 72 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
AV-6 DC AVERES EKF series DC circuit breakers with K time-current characteristic are designed for rapid control of DC electrical circuit sections, as well as for protection against overload and short-circuit currents in industrial installations with high inrush currents. Rated breaking capacity (Icn) is 6 kA. Circuit breakers comply with GOST IEC 60947-2. Full set of accessories for functional expansion. 10-year warranty.
Additional equipment possible
Yes
Mounting installation depth
74 мм
For flush mounting
Yes
Overvoltage category
3
Current limiting class
3
Number of protected poles
3
Rated breaking capacity in accordance with EN 60898
6 кА
Rated impulse voltage
6 кВ
Rated voltage
750 В
Rated insulation voltage Ui
1 000 В
Rated current
6 А
Total number of poles
3
Ambient operating temperature to
60 град.C
Ambient operating temperature from
-40...60 град.C
Current type
DC (direct)
With switched neutral conductor
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
1...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1...25 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Tripping characteristic
K
Width in modular units
3
