EKF
Automatic switch AV-6 DC 4P 63A (K) 6kA EKF AVERES mcb6-DC-4-63K-av
SKU: mcb6-DC-4-63K-av
ETIM: EC000042
17,097 ₽
Get back 170 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
AV-6 DC AVERES EKF series DC circuit breakers with K time-current characteristic are designed for rapid control of DC electrical circuit sections, as well as for protection against overload and short-circuit currents in industrial installations with high inrush currents. Rated breaking capacity (Icn) is 6 kA. Circuit breakers comply with GOST IEC 60947-2. Full set of accessories for functional expansion. 10-year warranty.
Additional equipment possible
Yes
Mounting installation depth
74 мм
For flush mounting
Yes
Overvoltage category
3
Current limiting class
3
Number of protected poles
4
Rated breaking capacity in accordance with EN 60898
6 кА
Rated impulse voltage
6 кВ
Rated voltage
1 000 В
Rated insulation voltage Ui
1 000 В
Rated current
63 А
Total number of poles
4
Ambient operating temperature to
60 град.C
Ambient operating temperature from
-40...60 град.C
Current type
DC (direct)
With switched neutral conductor
Yes
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
1...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1...25 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Tripping characteristic
K
Width in modular units
4
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
289 ₽
DEKraft Modular automatic circuit breaker 1p C 63A 4.5kA VA-101 DEKraft 11060DEK
SKU: 11060DEK
248 ₽
EKF Circuit breaker VA 47-63 1P 50A (B) 4.5kA EKF PROXIMA mcb4763-1-50B-pro
SKU: mcb4763-1-50B-pro
233 ₽
КЭАЗ Modular automatic circuit breaker 1p C 63A 4.5kA BA47-29-1C63-UHL3 KEAZ 318207
SKU: 318207
239 ₽
CHINT Modular circuit breaker 1P C 25A 6kA NXB-63 (R) CHINT 814016
