Контактор (группа IEK)
Automatic circuit breaker AV2M20SV-55-43-1500-MP4-UKHL3-NR220VAC-PE220VAC-3p3z-VKS 1500A; max current trip unit MRT4-MP; independent trip coil 220VAC; electromagnetic drive 220VAC; free contacts 3p3z Contactor 1042420
SKU: 1042420
ETIM: EC000228
1,280,523 ₽
Get back 12,805 ₽ in points
Analogues by specifications
No description available
Main circuit connection type
Rear connection
Built-in ground fault protection
No
Built-in motor drive
Yes
Short-time delayed short-circuit release range
540…18000 А
Setting range of overload protection device from
450…1500 А
Design
Withdrawable
Version
Withdrawable
Climatic version
UKhL3
Number of auxiliary NO contacts
3
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
3
Number of poles
3
Design
Slot-in device (withdrawable)
Motor drive optional
Yes
Electronic release available
Yes
Rated impulse withstand voltage
6
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
23 кА
Rated voltage
690 В
Rated voltage from
0...690 В
Rated current
1500 А
Rated continuous current Iu
1500 А
Suitable for DIN-rail mounting
No
Power loss
348 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Control element type
Other
Mains supply frequency
50/60 Гц
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
558866 ₽
CHINT Air circuit breaker 3p 2000A 80kA AC 220V type M NA1-3200-2000M stac. (R) CHINT 101126
