Generica (Группа IEK)

Circuit breaker VA47-29M 3P 16A 4.5kA C GENERICA MVA21-3-016-C-G

SKU: MVA21-3-016-C-G ETIM: EC000042

1,927 ₽

Get back 19 ₽ in points

Order multiple: 4 шт

Stock by warehouse

Manufacturer warehouse September 7 · Delivery to Smolensk Oblast on September 12 779 шт On order Manufacturer warehouse September 7 · Delivery to Smolensk Oblast on September 12 178 шт On order РЦ Калуга September 9 · Delivery to Smolensk Oblast on September 14 36 шт On order РЦ Москва 2 September 9 · Delivery to Smolensk Oblast on September 14 26 шт On order

Description Specifications Reviews

Weight per pole 0.085

Additional equipment possible No

Busbar connection capability PIN (pin)

For flush mounting Yes

Electric shock protection class 0

Current limiting class 3

Climatic version UKhL4

Number of protected poles 3

Number of poles 3

Maximum supply cable cross-section 25 кв.мм

Mech. endurance 10000

Explosion protection present Without explosion protection

Availability of residual current release No

Thermal release available Yes

Electromagnetic release present Yes

Electronic release available No

Rated impulse withstand voltage 4

Rated short-circuit breaking capacity Icu IEC 60898 at 230 V 4.5 кА

Rated short-circuit breaking capacity Icu IEC 60898 at 400 V 4.5 кА

Rated breaking capacity in accordance with EN 60898 4.5 кА

Rated voltage 400 В

Rated current 16.0 А

Total number of poles 3

Power loss 10.5 Вт

Ambient operating temperature to 50 град.C

Ambient operating temperature from -40...50 град.C

Operating mode Continuous-S1

Repairability No

Current type Alternating current (AC)

With time delay No

With switched neutral conductor No

Flexible stranded conductor cross-section up to 25 кв.мм

Stranded flexible conductor cross-section from 1...25 кв.мм

Solid conductor cross-section to 25 кв.мм

Solid conductor cross-section from 1...25 кв.мм

Tripping system Thermal, electromagnetic

Mounting method On DIN rail

IP protection rating IP20

Application area Domestic

Mounting rail type TN-35

Connection type Screw connection

Tripping characteristic It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.

Frequency 50 Гц

Frequency at 50 Гц

Frequency from 50 Гц

Width in modular units 3

Electrical endurance 4000
