EKF
Molded case circuit breaker AV-POWER-1/3 63A 100kA ETU2.0 EKF mccb-13-63H-2.0-av
SKU: mccb-13-63H-2.0-av
ETIM: EC000228
35,426 ₽
Get back 354 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
These are standard devices with the possibility of selecting and replacing trip units, including both thermomagnetic and electronic trip units, as well as trip units with earth leakage protection. The unified size of the trip unit module allows any trip unit to be installed on the base to achieve the required type of protection.
Main circuit connection type
Front side
Built-in ground fault protection
No
Built-in motor drive
No
Short-time delayed short-circuit release range
50...630 А
Overload protection device setting range to
63 А
Setting range of overload protection device from
25...63 А
Instantaneous short-circuit release setting range to
882 А
Instantaneous short-circuit release setting range from
50...882 А
Trip indicator present
Yes
Number of auxiliary NO contacts
0
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
0
Number of poles
3
Design
Complete unit in enclosure
DIN rail mounting (O-type) optional
No
Motor drive optional
Yes
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
100 кА
Rated voltage up to
690 В
Rated voltage from
400...690 В
Rated continuous current Iu
63 А
Suitable for DIN-rail mounting
No
With minimum voltage protection
No
IP protection rating
IP30
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Bolted connection
Control element type
Lever (toggle)
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
5020 ₽
EKF Molded case circuit breaker AV-POWER-1/3 32A 35kA TR EKF mccb-13-32-TR-av
SKU: mccb-13-32-TR-av
1346 ₽
Legrand (группа IEK) DRX125 thermomagnetic 25A 1P 36KA 027042 Legrand
SKU: 027042
4768 ₽
КЭАЗ Circuit breaker 2p 10A 10In 2kA AP50B 2M U3 400V AC/220V DC additional contacts 1changeover KEAZ 106488
