EKF
Moulded case circuit breaker AV-POWER-1/3 63A 50kA ETU2.0 EKF mccb-13-63-2.0-av
SKU: mccb-13-63-2.0-av
ETIM: EC000228
18,811 ₽
Get back 188 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
From AV POWER-1 to AV POWER-4. These are standard devices with the possibility of selecting and replacing trip units, including both thermomagnetic and electronic trip units, as well as trip units with leakage current protection. The unified size of the trip unit module allows any trip unit to be installed on the base to achieve the required type of protection. Depending on the required type of protection, any other trip unit block can be selected.
Built-in ground fault protection
No
Short-time delayed short-circuit release range
50...630 А
Overload protection device setting range to
63 А
Setting range of overload protection device from
25...63 А
Instantaneous short-circuit release setting range to
882 А
Instantaneous short-circuit release setting range from
50...882 А
Trip indicator present
Yes
Number of auxiliary NO contacts
0
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
0
Number of poles
3
Design
Complete unit in enclosure
Motor drive optional
Yes
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
50 кА
Rated voltage up to
690 В
Rated voltage from
400...690 В
Rated continuous current Iu
63 А
Suitable for DIN-rail mounting
No
With minimum voltage protection
No
IP protection rating
IP30
Main electrical circuit connection type
Bolted connection
Control element type
Lever (toggle)
