Switches are designed to conduct current in normal mode and disconnect current during short circuits and overloads, as well as for infrequent operational switching of electrical circuits, and are designed for operation in electrical installations with a rated voltage of up to 660 V AC at 50, 60 Hz and up to 220 V DC. Included in the Ministry of Industry and Trade register.
| Main circuit connection type | Front connection |
| Built-in ground fault protection | No |
| Built-in motor drive | No |
| Height | 200.0 мм |
| Depth | 300.0 мм |
| Overload protection device setting range to | 100 А |
| Setting range of overload protection device from | 100 А |
| Instantaneous short-circuit release setting range to | 1250 А |
| Instantaneous short-circuit release setting range from | 1250 А |
| Trip indicator present | Yes |
| Design | Stationary |
| Number of auxiliary NO contacts | 1 |
| Number of auxiliary break contacts | 2 |
| Number of poles | 3 |
| Design | Complete unit in enclosure |
| Motor drive optional | No |
| Rated service short-circuit breaking capacity Ics | 15 |
| Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz | 20 кА |
| Rated voltage up to | 660 В |
| Rated voltage from | 0 В |
| Rated current | 100 А |
| Rated continuous current Iu | 100 А |
| Suitable for DIN-rail mounting | No |
| Power loss | 96 Вт |
| With minimum voltage protection | Yes |
| Tripping system | Thermal-magnetic |
| IP protection rating | IP20 |
| Product/component type | Moulded case circuit breaker |
| Main electrical circuit connection type | Screw connection |
| Control element type | Lever (toggle) |
| Width | 200.0 мм |
