Circuit breaker VA08-0405N-331870-00UHL3 160A 660V setting 5120A HP380AC PE380AC long leads front connection busbar or two busbars/cables copper Contactor 1043597
SKU: 1043597
ETIM: EC000228
375,804 ₽
Get back 3,758 ₽ in points
Analogues by specifications
Stock by warehouse
Switches are designed for conducting current in normal mode and disconnecting current during short circuits, overloads, and unacceptable voltage drops, as well as for infrequent (up to 6 times per day) operational switching of electrical circuits and are designed for operation in electrical installations at a rated voltage of up to 440 V DC and up to 660 V AC at a frequency of 50 and 60 Hz. Included in the Ministry of Industry and Trade register.
Main circuit connection type
Front connection
Built-in ground fault protection
Yes
Built-in motor drive
Yes
Height
260.0 мм
Height
260.0 мм
Depth
350.0 мм
Short-time delayed short-circuit release range
240…1600 А
Overload protection device setting range to
160 А
Setting range of overload protection device from
80…160 А
Instantaneous short-circuit release setting range to
1920 А
Instantaneous short-circuit release setting range from
320…1920 А
Design
Withdrawable
Version
Withdrawable
Number of auxiliary NO contacts
3
Number of auxiliary break contacts
3
Number of poles
3
Design
Slot-in device (withdrawable)
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
30
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
30 кА
Rated voltage up to
660 В
Rated voltage from
0...660 В
Rated current
160 А
Rated continuous current Iu
160 А
Suitable for DIN-rail mounting
No
Power loss
75 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Lever (toggle)
Width
260.0 мм
