Circuit breaker ВА51-39-630А-341110-6300-660В-20УХЛ3 ВК4З4Р front copper bus Contactor 1002288
SKU: 1002288
ETIM: EC000228
34,104 ₽
Get back 341 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Switches are designed for conducting current in normal mode and disconnecting current during short circuits, overloads, and impermissible voltage drops, as well as for infrequent (up to 6 per day) operational switching on and off of electrical circuits and are designed for operation in electrical installations with a nominal voltage of up to 660 V AC at a frequency of 50 and 60 Hz and up to 440 V DC. Included in the Ministry of Industry and Trade register.
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
No
Height
250.0 мм
Height
250.0 мм
Depth
270.0 мм
Overload protection device setting range to
630 А
Setting range of overload protection device from
630…630 А
Instantaneous short-circuit release setting range to
6300 А
Instantaneous short-circuit release setting range from
6300…6300 А
Design
Stationary
Number of auxiliary NO contacts
0
Number of auxiliary break contacts
0
Number of poles
3
Design
Device complete with housing
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
35
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
35 кА
Rated voltage up to
660 В
Rated voltage from
0...660 В
Rated current
630 А
Rated continuous current Iu
630 А
Suitable for DIN-rail mounting
No
Power loss
150 Вт
With minimum voltage protection
Yes
Tripping system
Thermal-magnetic
IP protection rating
IP20
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Lever (toggle)
Width
250.0 мм
