Контактор (группа IEK)
Circuit breaker ВА53-41-342510-20УХЛ3 1000A stationary МРТ2-МП РНН220AC front copper busbar Contactor 1004568
SKU: 1004568
ETIM: EC000228
165,986 ₽
Get back 1,659 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
No
Height
272.0 мм
Height
272.0 мм
Depth
217.0 мм
Short-time delayed short-circuit release range
450…12000 А
Overload protection device setting range to
1000 А
Setting range of overload protection device from
300…1000 А
Instantaneous short-circuit release setting range to
12000 А
Instantaneous short-circuit release setting range from
600…12000 А
Version
Stationary
Design
Stationary
Number of auxiliary NO contacts
2
Number of auxiliary break contacts
2
Number of poles
3
Design
Device complete with housing
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
101.25
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
135 кА
Rated voltage up to
690 В
Rated voltage from
0...690 В
Rated current
1000 А
Rated continuous current Iu
1000 А
Suitable for DIN-rail mounting
No
Power loss
253 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP20
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Lever (toggle)
Width
541.0 мм
