Systeme Electric
Miniature circuit breaker 1p B 50A 10kA Systeme9 230V SE S9F31150 Systeme Electric
SKU: S9F31150
ETIM: EC000042
2256 ₽
Preorder
S9FH circuit breaker, Systeme9 series, Systeme Electric, 1-pole, rated current 50 A, characteristic B, Icn = 10 kA, Icu = 15 kA. Complies with GOST IEC 60898-1 and GOST IEC 60947-2 standards. Used in 230 V electrical networks. Designed to protect circuits from overloads and short circuits. Equipped with double safe terminals for separate conductor mounting, an instantaneous switching mechanism, and indicators for contact group status and trip due to fault. Mounts on a DIN rail using two-position clips, with the possibility of removal without removing the PIN busbar.
| Mounting installation depth | 45 мм |
| Number of protected poles | 1 |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 10 кА |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V | 15 кА |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 15 кА |
| Rated impulse voltage | 6 кВ |
| Rated voltage | 230 В |
| Rated insulation voltage Ui | 500 В |
| Rated current | 50 А |
| Total number of poles | 1 |
| Ambient operating temperature to | 70 град.C |
| Ambient operating temperature from | -35 град.C |
| Current type | Alternating current (AC) |
| Flexible stranded conductor cross-section up to | 16 кв.мм |
| Stranded flexible conductor cross-section from | 1 кв.мм |
| Solid conductor cross-section to | 25 кв.мм |
| Solid conductor cross-section from | 1 кв.мм |
| Pollution degree (number) | 3 |
| IP protection rating | IP20 |
| Tripping characteristic | Please provide the text you would like me to translate. |
| Frequency at | 60 Гц |
| Frequency from | 50 Гц |
| Width in modular units | 1 |
