Circuit breaker 2p D 63A 10kA Systeme9 400V SE S9F33263 Systeme Electric
SKU: S9F33263
ETIM: EC000042
6,423 ₽
Get back 64 ₽ in points
Analogues by specifications
Stock by warehouse
S9FH circuit breaker, Systeme9 series, Systeme Electric, 2-pole, rated current 63 A, characteristic D, Icn = 10 kA, Icu = 15 kA. Complies with the requirements of GOST IEC 60898-1 and GOST IEC 60947-2 standards. Used in electrical networks with a voltage of 400 V. Designed to protect circuits from overloads and short-circuit currents. Equipped with double safe terminals for separate conductor installation, an instantaneous switching mechanism, and indicators for contact group status and fault tripping. Mounts on a DIN rail using two-position clips, with the possibility of disassembly without removing the PIN busbar.
Mounting installation depth
45 мм
Number of protected poles
2
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
10 кА
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V
30 кА
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V
15 кА
Rated impulse voltage
6 кВ
Rated voltage
400 В
Rated insulation voltage Ui
500 В
Rated current
63 А
Total number of poles
2
Ambient operating temperature to
70 град.C
Ambient operating temperature from
-35 град.C
Current type
Alternating current (AC)
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Tripping characteristic
It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency at
60 Гц
Frequency from
50 Гц
Width in modular units
2
