No description available
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
Yes
Height
272.0 мм
Depth
297.0 мм
Short-time delayed short-circuit release range
450…12000 А
Overload protection device setting range to
1000 А
Setting range of overload protection device from
300…1000 А
Instantaneous short-circuit release setting range to
12000 А
Instantaneous short-circuit release setting range from
600…12000 А
Design
Stationary
Number of auxiliary NO contacts
4
Number of auxiliary break contacts
3
Number of poles
3
Design
Device complete with housing
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
41.25
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
55 кА
Rated voltage up to
690 В
Rated voltage from
0...690 В
Rated current
1000 А
Rated continuous current Iu
1000 А
Suitable for DIN-rail mounting
No
Power loss
253 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Lever (toggle)
Width
546.0 мм
