Circuit breaker VA55-43-340010-20UHL3 1600A MRT2-MP front aluminum busbar Contactor 1002558
SKU: 1002558
ETIM: EC000228
245,408 ₽
Get back 2,454 ₽ in points
Analogues by specifications
No description available
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
No
Height
452.0 мм
Depth
231.0 мм
Short-time delayed short-circuit release range
720…19200 А
Overload protection device setting range to
1600 А
Setting range of overload protection device from
480…1600 А
Instantaneous short-circuit release setting range to
19200 А
Instantaneous short-circuit release setting range from
960…19200 А
Design
Stationary
Version
Stationary
Number of auxiliary NO contacts
0
Number of auxiliary break contacts
0
Number of poles
3
Design
Device complete with housing
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
41.25
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
55 кА
Rated voltage up to
690 В
Rated voltage from
0...690 В
Rated current
1600 А
Rated continuous current Iu
1600 А
Suitable for DIN-rail mounting
No
Power loss
324 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP20
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Lever (toggle)
Width
551.0 мм
