Контактор (группа IEK)
Circuit breaker ВА08-0405Н-351850-00УХЛ3 400A 660V setting 12800A HP220AC with terminals 1/3/5 up long terminals rear connection busbar or two busbars/cables aluminum Contactor 1033607
SKU: 1033607
ETIM: EC000228
270,000 ₽
Get back 2,700 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Main circuit connection type
Rear connection
Built-in ground fault protection
Yes
Built-in motor drive
No
Height
360.0 мм
Depth
430.0 мм
Short-time delayed short-circuit release range
180…4000 А
Overload protection device setting range to
400 А
Setting range of overload protection device from
120…400 А
Instantaneous short-circuit release setting range to
4800 А
Instantaneous short-circuit release setting range from
180…4800 А
Version
Withdrawable
Design
Withdrawable
Number of auxiliary NO contacts
3
Number of auxiliary break contacts
4
Number of poles
3
Design
Slot-in device (withdrawable)
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
30
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
30 кА
Rated voltage up to
660 В
Rated voltage from
0...660 В
Rated current
400 А
Rated continuous current Iu
400 А
Suitable for DIN-rail mounting
No
Power loss
75 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Extended rotary handle (wide grip)
Width
360.0 мм
