Systeme Electric
Circuit breaker 3p B 4A 6kA Systeme9 400V SE S9F21304 Systeme Electric
SKU: S9F21304
ETIM: EC000042
4,044 ₽
Analogues by specifications
Stock by warehouse
S9FN circuit breaker, Systeme9 series, Systeme Electric, 3-pole, rated current 4 A, characteristic B, Icn = 6 kA, Icu = 10 kA. Complies with GOST IEC 60898-1 and GOST IEC 60947-2 standards. Applied in electrical networks with voltage 400 V. Designed to protect circuits from overloads and short-circuit currents. Equipped with double safe terminals for separate conductor mounting, instantaneous switching mechanism, indicators for contact group status and fault tripping. Mounts on DIN rail using two-position latches, with the possibility of disassembly without removing the PIN busbar.
Mounting installation depth
45 мм
Number of protected poles
3
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
6 кА
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V
20 кА
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V
10 кА
Rated impulse voltage
6 кВ
Rated voltage
400 В
Rated insulation voltage Ui
500 В
Rated current
4 А
Total number of poles
3
Ambient operating temperature to
70 град.C
Ambient operating temperature from
-35 град.C
Current type
Alternating current (AC)
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Tripping characteristic
Please provide the text you would like me to translate.
Frequency at
60 Гц
Frequency from
50 Гц
Width in modular units
3
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
755 ₽
DEKraft Modular circuit breaker 3P C 20A 4.5kA VA-101 DEKraft 11079DEK
SKU: 11079DEK
35129 ₽
КЭАЗ Modular automatic switch 4p Z 2A 6kA OptiDin BM63-4Z2-УХЛ3-РЕГ КЭАЗ 280607
