Эра
Residual current circuit breaker 1P+N C 16A 30mA type AC protection 230V RCBO 4.5kA PRO D32E2C16AC30P AD32 electronic Era B0057351
SKU: Б0057351
ETIM: EC000905
932 ₽
Get back 9 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Residual Current Circuit Breaker (RCCB) - Residual Current Circuit Breakers (RCCB) are designed to protect people from electric shock in case of insulation damage in electrical installations, to prevent fires due to leakage currents to the ground, and to protect against overload and short circuits. Recommended for protecting group lines supplying outdoor sockets, sockets, and lighting in basements and garages.
Mounting installation depth
71 мм
For flush mounting
Yes
False tripping protection
No
Number of protected poles
1
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
4.5 кА
Rated short-circuit breaking capacity per EN 61009
4.5 кА
Rated voltage
230 В
Rated current
16 А
Rated leakage current
.03 мА
Total number of poles
2
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Residual current type
Alternating current (AC)
Tripping characteristic
Without time delay
Tripping characteristic
C
Frequency (Hz)
50 Hz
Width in modular units
2
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
662 ₽
TDM ELECTRIC AVDT 32 2P(1P+N) C16A 30mA 4.5kA type AC TDM SQ0202-0503
SKU: SQ0202-0503
1492 ₽
EKF RCBO AD-4 4P 32A characteristic C 30mA type AC electronic 6kA PROXIMA EKF DA4-6-32-30-pro
SKU: DA4-6-32-30-pro
888 ₽
КЭАЗ RCBO 2P C 32A 30mA type AC 4.5kA AVDT32-22C32-AC UHL4 KEAZ 318364
SKU: 318364
1124 ₽
КЭАЗ 4P C 32A 30mA type AC 4.5kA differential current circuit breaker AD14-42C32-AC UHL4 KEAZ 318762
