Legrand
RCBO 2P (1P+N) C 32A 30mA type AC 6kA RX3 IEK Leg 419402 Legrand (IEK group)
SKU: 419402
ETIM: EC000905
26,557 ₽
Get back 265 ₽ in points
Order multiple: 6 шт
Analogues by specifications
Stock by warehouse
No description available
Mounting installation depth
48 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage protection
No
Overvoltage category
2
Protection class per GOST IEC 61140
0
Current limiting class
3
Climatic version
UKhL3.1
Number of protected poles
1
Number of poles
6
Maximum supply cable cross-section
16 кв.мм
Mechanical durability
20000
Tightening torque of contact terminal screws
2
Availability of residual current release
Yes
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
8
Rated non-tripping residual current
34
Rated differential making and breaking capacity
1500
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
4 кВ
Rated voltage
234 В
Rated insulation voltage Ui
500 В
Rated current
32 А
Rated leakage current
0.03 мА
Total number of poles
2
Breaking capacity per IEC 61009-1
6000
Ambient operating temperature to
60 град.C
Ambient operating temperature from
-25 град.C
Operating mode
Continuous
Breaking capacity
6.0 кА
Current type
Alternating current (AC)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
.75 кв.мм
Solid conductor cross-section to
16 кв.мм
Solid conductor cross-section from
.75 кв.мм
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Operating temperature
-25...70
Residual current type
Alternating current (AC)
Connection type
Screw connection
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
6
Electrical wear resistance
10000
