Эра
Residual current circuit breaker 2p (1P+N) C 50A 100mA type AC 6kA AD-32 electronic protection 230V PRO D326E2C50AC100P Era B0059121
SKU: Б0059121
ETIM: EC000905
1,731 ₽
Get back 17 ₽ in points
Analogues by specifications
No description available
Mounting installation depth
72 мм
For flush mounting
Yes
False tripping protection
No
Number of protected poles
1
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated short-circuit breaking capacity per EN 61009
6 кА
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
50 А
Rated leakage current
Please provide the text you would like me to translate. мА
Total number of poles
2
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Residual current type
Alternating current (AC)
Tripping characteristic
Without time delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
2
