RCBO 2P (1P+N) C 63A 100mA type AC 6kA PRIZMA TOKOV ELECTRIC TKE-PZ60-RCBO-2-63-100-AC

SKU: TKE-PZ60-RCBO-2-63-100-AC ETIM: EC000905

1,252 ₽

Get back 12 ₽ in points

Stock by warehouse

Transit warehouse August 20 · Delivery to Smolensk Oblast on August 27 104 шт On order РЦ Тверь August 21 · Delivery to Smolensk Oblast on August 28 99 шт On order РЦ Тула August 21 · Delivery to Smolensk Oblast on August 28 39 шт On order

Description Specifications Reviews

Mounting installation depth 50 мм

Number of protected poles 1

Rated short-circuit breaking capacity Icn per EN 61009-1 6 кА

Rated impulse voltage 6 кВ

Rated voltage 230 В

Rated insulation voltage Ui 400 В

Rated current 63 А

Rated leakage current Please provide the text you would like me to translate. мА

Total number of poles 2

Ambient operating temperature to 50 град.C

Ambient operating temperature from -25 град.C

Current type Alternating current (AC)

With switched neutral conductor Yes

Flexible stranded conductor cross-section up to 10 кв.мм

Stranded flexible conductor cross-section from 1 кв.мм

Solid conductor cross-section to 16 кв.мм

Solid conductor cross-section from 1 кв.мм

IP protection rating IP20

Residual current type Alternating current (AC)

Tripping characteristic Without time delay

Tripping characteristic It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.

Frequency (Hz) 50 Hz

Width in modular units 2
