Systeme Electric
Residual current circuit breaker 2p (1P+N) C 6A 30mA type A 4.5kA City9 18mm SE C9D53606 Systeme Electric
SKU: C9D53606
ETIM: EC000905
5,123 ₽
Get back 51 ₽ in points
Analogues by specifications
Stock by warehouse
No description available
Mounting installation depth
60.5 мм
For flush mounting
Yes
Number of protected poles
1
Rated breaking capacity per IEC 60947-2
4.5 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
4.5 кА
Rated impulse voltage
4 кВ
Rated voltage
230 В
Rated insulation voltage Ui
400 В
Rated current
6 А
Rated leakage current
.03 мА
Total number of poles
2
Ambient operating temperature to
70 град.C
Ambient operating temperature from
-35 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
10 кв.мм
Solid conductor cross-section to
16 кв.мм
Solid conductor cross-section from
16 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Residual current type
Please provide the text you would like me to translate.
Tripping characteristic
Without time delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
1
