TOKOV ELECTRIC
Residual current circuit breaker 2p (1P+N) C 6A 30mA type AC 6kA PRIZMA TOKOV ELECTRIC TKE-PZ60-RCBO-2-6-30-AC
SKU: TKE-PZ60-RCBO-2-6-30-AC
ETIM: EC000905
1,252 ₽
Get back 12 ₽ in points
Analogues by specifications
Stock by warehouse
TOKOV ELECTRIC PRIZMA 2P (1P+N) C6 30 mA AC type residual current circuit breaker is designed to protect single-phase electrical circuits from overload, short circuit, and leakage currents. Designed for a rated current of 6 A and a leakage current of 30 mA, it provides protection for persons against electric shock and line protection. It has a C tripping characteristic and a breaking capacity of 6 kA. The device occupies 2 modules in the distribution board, AC leakage type, IP20 protection rating, intended for indoor installation in electrical panels.
Mounting installation depth
50 мм
Number of protected poles
1
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
400 В
Rated current
6 А
Rated leakage current
.03 мА
Total number of poles
2
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
16 кв.мм
Solid conductor cross-section from
1 кв.мм
IP protection rating
IP20
Residual current type
Alternating current (AC)
Tripping characteristic
Without time delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
2
