КЭАЗ
Residual current circuit breaker 2P C 32A 30mA type AC 4.5kA OptiDin D63-22C32-AC-У3 with overcurrent protection КЭАЗ 328101
SKU: 328101
ETIM: EC000905
2,471 ₽
Analogues by specifications
No description available
For flush mounting
No
False tripping protection
No
Number of protected poles
1
Rated breaking capacity in accordance with EN 60898
4.5 кА
Rated breaking capacity per IEC 60947-2
4.5 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
4.5 кА
Rated impulse voltage
4 кВ
Rated voltage
230 В
Rated insulation voltage Ui
230 В
Rated current
32 А
Rated leakage current
.03 мА
Total number of poles
2
Ambient operating temperature to
55 град.C
Ambient operating temperature from
-40 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
16 кв.мм
Solid conductor cross-section from
1 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
Alternating current (AC)
Tripping characteristic
Without time delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
2
