Эра
4P (3P+N) AC residual current circuit breaker 63A 100mA C 4.5kA AD-32 electronic protection 230V PRO D32E4C63AC100P Era B0057804
SKU: Б0057804
ETIM: EC000905
1,714 ₽
Get back 17 ₽ in points
Analogues by specifications
No description available
Mounting installation depth
71 мм
For flush mounting
Yes
False tripping protection
No
Number of protected poles
3
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
4.5 кА
Rated short-circuit breaking capacity per EN 61009
4.5 кА
Rated voltage
400 В
Rated insulation voltage Ui
500 В
Rated current
63 А
Rated leakage current
Please provide the text you would like me to translate. мА
Total number of poles
4
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Residual current type
Alternating current (AC)
Tripping characteristic
Without time delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
4
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
1595 ₽
Контактор (группа IEK) Differential circuit breaker AD-063 2P 16A Idn-30mA type A CONTACTOR 7000601
SKU: 7000601
1818 ₽
CHINT Residual current circuit breaker 2p D 40A 30mA type AC 6kA NXBLE-63 (R) CHINT 982539
SKU: 982539
1762 ₽
DEKraft Residual current circuit breaker 2p (1P+N) C 40A 30mA type AC 4.5kA DIF-103 DEKraft 16056DEK
