КЭАЗ
4P C 20A 100mA Type A 6kA OptiDin VD63 УХЛ4 КЭАЗ 103485 differential current circuit breaker
SKU: 103485
ETIM: EC000905
8,791 ₽
Get back 87 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Mounting installation depth
5.5 мм
For flush mounting
No
False tripping protection
No
Number of protected poles
3
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated short-circuit breaking capacity per EN 61009
6 кА
Rated impulse voltage
4 кВ
Rated voltage
400 В
Rated insulation voltage Ui
400 В
Rated current
20 А
Rated leakage current
.1 мА
Total number of poles
4
Ambient operating temperature to
55 град.C
Ambient operating temperature from
-40 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Residual current type
A
Tripping characteristic
Without time delay
Tripping characteristic
C
Frequency (Hz)
50 Hz
Width in modular units
7
