DEKraft
Circuit breaker for motor protection 3p 0.16-0.25A 100kA VA-451 rotary handle thermomagnetic trip DEKraft 29131DEK
SKU: 29131DEK
ETIM: EC000074
3,673 ₽
Get back 36 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
VA-451 series circuit breaker with combined trip unit, adjustable in the range 0.16 – 0.25 A, with a rotary control handle. VA-451 series circuit breakers are designed for controlling and protecting electric motors from overload, short circuit, and phase failure in industrial, infrastructure, and construction facilities; they are installed on a DIN rail or on a mounting plate using screws. Accessories are compatible with VA-431 series.
Height
53 мм
Depth
105 мм
Overload protection device setting range to
.25 А
Setting range of overload protection device from
.16 А
Number of poles
3
Design
Built-in fixed-mounted device
Rated power at AC-3, 400 V
.06 кВт
Rated ultimate breaking capacity Icu at 400V AC
100 кА
Rated voltage at
690 В
Rated voltage from
690 В
Rated continuous current Iu
.25 А
With overheating protection
Yes
Tripping system
Thermomagnetic
With built-in auxiliary switch
No
With built-in undervoltage release
No
IP protection rating
IP20
Main electrical circuit connection type
Screw connection
Control element type
Rotary switch
Phase failure sensitive
Yes
Width
94 мм
