DEKraft
Motor protection circuit breaker 3p 1.6-2.5A 100kA VA-451 with rotary handle and thermomagnetic release DEKraft 29136DEK
SKU: 29136DEK
ETIM: EC000074
Price on request
Analogues by specifications
Stock by warehouse
VA-451 series automatic circuit breaker with a combined trip unit, adjustable in the range of 1.6 – 2.5 A, with a rotary operating handle. VA-451 series automatic circuit breakers are designed for the control and protection of electric motors from overload, short circuit, and phase failure in industrial, infrastructure, and construction facilities; they are installed on a DIN rail or on a mounting plate using screws. Accessories are compatible with the VA-431 series.
Height
53 мм
Depth
105 мм
Overload protection device setting range to
2.5 А
Setting range of overload protection device from
1.6 А
Number of poles
3
Design
Built-in fixed-mounted device
Rated power in AC-3 mode, 230 V
.37 кВт
Rated power at AC-3, 400 V
.75 кВт
Rated ultimate breaking capacity Icu at 400V AC
100 кА
Rated voltage at
690 В
Rated voltage from
690 В
Rated continuous current Iu
2.5 А
With overheating protection
Yes
Tripping system
Thermomagnetic
With built-in auxiliary switch
No
With built-in undervoltage release
No
IP protection rating
IP20
Main electrical circuit connection type
Screw connection
Control element type
Rotary switch
Phase failure sensitive
Yes
Width
94 мм
