Motor protection circuit breaker 3p 25.0A 15kA VA-451 rotary handle magnetic release DEKraft 29163DEK
SKU: 29163DEK
ETIM: EC000074
4,277 ₽
Get back 42 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
VA-451 series circuit breaker with magnetic release and rotary operating handle. VA-451 series circuit breakers are designed for the control and protection of electric motors against overload, short circuit, and phase failure in industrial, infrastructure, and construction facilities; they are installed on a DIN rail or on a mounting plate using screws. Accessories are compatible with the VA-431 series.
Height
53 мм
Depth
105 мм
Number of poles
3
Design
Built-in fixed-mounted device
Rated power in AC-3 mode, 230 V
5.5 кВт
Rated power at AC-3, 400 V
11 кВт
Rated ultimate breaking capacity Icu at 400V AC
50 кА
Rated voltage at
690 В
Rated voltage from
690 В
Rated continuous current Iu
25 А
With overheating protection
Yes
Tripping system
Electromagnetic
With built-in auxiliary switch
No
With built-in undervoltage release
No
IP protection rating
IP20
Main electrical circuit connection type
Screw connection
Control element type
Rotary switch
Phase failure sensitive
Yes
Width
94 мм
