Modular circuit breaker YON max (YON max) type MD125, 2 poles, characteristic D, 80A, 10kA MD125H-2PD80 DKC

SKU: MD125H-2PD80

ETIM: EC000042

1525 ₽

Price list (incl. VAT): 1962 ₽

Available August 5

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	120	шт	August 5	August 5

Select a warehouse to order

Description Specifications Reviews

Additional equipment possible	Yes
Mounting installation depth	77.3 мм
Overvoltage category	4
Current limiting class	3
Number of protected poles	2
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V	10 кА
Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V	10 кА
Rated breaking capacity in accordance with EN 60898	10 кА
Rated impulse voltage	10 кВ
Rated voltage	400 В
Rated insulation voltage Ui	500 В
Rated current	80 А
Total number of poles	2
Ambient operating temperature to	40 град.C
Ambient operating temperature from	-25 град.C
Current type	Alternating current (AC)
With switched neutral conductor	No
Flexible stranded conductor cross-section up to	35 кв.мм
Stranded flexible conductor cross-section from	35 кв.мм
Solid conductor cross-section to	50 кв.мм
Solid conductor cross-section from	50 кв.мм
Pollution degree (number)	3
IP protection rating	IP20
Tripping characteristic	It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency at	50 Гц
Frequency from	50 Гц
Width in modular units	3
