LS Electric
Air circuit breaker 3p 3200A 65kA Metasol AS-32E3-32A M2D2D2BX AC6U0A (sale only in comp. with basket; basket is ordered separately) LS Electric 286904128B
SKU: 286904128B
ETIM: EC000228
840,845 ₽
Analogues by specifications
• PURPOSE
Circuit breaker is a mechanical switching device capable of making, carrying, and breaking currents under normal circuit conditions, as well as making, carrying for a specified time, and automatically breaking currents under specified abnormal circuit conditions, such as short-circuit currents.
• APPLICATION
Used in low-voltage electrical networks for switching and protecting electrical networks and devices for various purposes.
• PRINCIPLE OF OPERATION
Switching on-off is performed by a lever; wires are connected using bolt or screw connections. The circuit is switched by moving and stationary contacts. The moving contact is spring-loaded; the spring provides the force for rapid contact separation. The trip mechanism is actuated by one of two trip units: thermal or magnetic.
• ADDITIONAL ACCESSORIES OR ACCESSORIES
The standard configuration includes the product itself
Built-in ground fault protection
Yes
Overload protection device setting range to
3200 А
Setting range of overload protection device from
1600 А
Trip indicator present
Yes
Number of auxiliary NO contacts
5
Number of auxiliary break contacts
5
Number of poles
3
Design
Built-in withdrawable device
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
65 кА
Rated continuous current Iu
3200 А
Suitable for DIN-rail mounting
No
With minimum voltage protection
Yes
