DKC
Air circuit breaker YON pro ANX08N 3P 800 A 66 kA, frame size S, trip unit ETH, withdrawable, horizontal/vertical connection, control 220 V AC ANX08NS3DH722200K DKC
SKU: ANX08NS3DH722200K
ETIM: EC000228
578,467 ₽
Get back 5,784 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
YON pro ANX series air circuit breaker is designed for operation in low voltage networks up to 690 V. It is used for making and breaking load currents, as well as for protection against overloads, short circuits, and ground faults. Rated current 800 A, breaking capacity 66 kA, 3-pole, withdrawable type, freely orientable power terminals, ETH trip unit, 220 V AC control
Built-in ground fault protection
Yes
Overload protection device setting range to
800 А
Setting range of overload protection device from
320 А
Number of auxiliary NO contacts
6
Number of auxiliary changeover contacts
6
Number of auxiliary break contacts
6
Number of poles
3
Design
Built-in withdrawable device
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
66 кА
Rated voltage up to
690 В
Rated voltage from
400 В
Rated continuous current Iu
800 А
Suitable for DIN-rail mounting
No
With minimum voltage protection
No
IP protection rating
IP20
