DKC
Air circuit breaker YON AGS12N 3P 1250 A 65 kA, frame size S, trip unit 3M, withdrawable, control 220 V AC, horizontal connection AGS12N-S3DH-5-222K DKC
SKU: AGS12N-S3DH-5-222K
ETIM: EC000228
443,796 ₽
Get back 4,437 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Air circuit breaker YON max series AGS is designed for operation in low voltage networks up to 415 V. It is used for switching operations, as well as for protection against overloads, short circuits, and ground faults. Rated current 1250 A, breaking capacity 65 kA, 3-pole, withdrawable version, trip unit 3M, control 220V AC
Built-in ground fault protection
Yes
Overload protection device setting range to
1250 А
Setting range of overload protection device from
500 А
Instantaneous short-circuit release setting range to
50000 А
Instantaneous short-circuit release setting range from
1250 А
Trip indicator present
Yes
Number of auxiliary NO contacts
6
Number of auxiliary changeover contacts
4
Number of auxiliary break contacts
6
Number of poles
3
Design
Built-in withdrawable device
Motor drive optional
Yes
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
65 кА
Rated voltage up to
415 В
Rated voltage from
380 В
Rated continuous current Iu
1250 А
Suitable for DIN-rail mounting
No
With minimum voltage protection
No
IP protection rating
IP20
