DKC
Air circuit breaker YON AGS32X 3P 3200 A 100 kA, frame size L, trip unit 3H, withdrawable, control 220 V AC, horizontal connection AGS32X-L3DH-6-222K DKC
SKU: AGS32X-L3DH-6-222K
ETIM: EC000228
699,601 ₽
Get back 6,996 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Air circuit breaker YON max series AGS is designed for operation in low voltage networks up to 415 V. It is used for switching operations, as well as for protection against overloads, short circuits, and ground faults. Rated current 3200 A, breaking capacity 100 kA, 3-pole, withdrawable version, trip unit 3H, control 220V AC
Built-in ground fault protection
Yes
Overload protection device setting range to
3200 А
Setting range of overload protection device from
1280 А
Instantaneous short-circuit release setting range to
100000 А
Instantaneous short-circuit release setting range from
3200 А
Trip indicator present
Yes
Number of auxiliary NO contacts
6
Number of auxiliary changeover contacts
6
Number of auxiliary break contacts
6
Number of poles
3
Design
Built-in withdrawable device
Motor drive optional
Yes
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
100 кА
Rated voltage up to
415 В
Rated voltage from
380 В
Rated continuous current Iu
3200 А
Suitable for DIN-rail mounting
No
With minimum voltage protection
No
IP protection rating
IP20
