Systeme Electric
Motor protection circuit breaker GM3P 17-25A comb. trip rot. handle screw clamp SE GM3P25 Systeme Electric
SKU: GM3P25
ETIM: EC000074
34,148 ₽
Get back 341 ₽ in points
Analogues by specifications
SystemePact GM3P series motor protection circuit breaker with combined trip unit, adjustable in the range 17 - 25 A, with rotary handle and screw terminals. GM3P circuit breakers are designed for controlling and protecting electric motors from overload and short circuit in industrial, infrastructure, and construction facilities; they are installed on a DIN rail or on a mounting plate using screws.
Height
139 мм
Depth
136 мм
Overload protection device setting range to
25 А
Setting range of overload protection device from
17 А
Number of poles
3
Design
Built-in fixed-mounted device
Rated power in AC-3 mode, 230 V
5.5 кВт
Rated power at AC-3, 400 V
11 кВт
Rated ultimate breaking capacity Icu at 400V AC
100 кА
Rated voltage at
690 В
Rated voltage from
690 В
Rated continuous current Iu
25 А
With overheating protection
Yes
Tripping system
Thermomagnetic
With built-in auxiliary switch
No
With built-in undervoltage release
No
IP protection rating
IP20
Main electrical circuit connection type
Screw connection
Control element type
Rotary switch
Phase failure sensitive
Yes
Width
55 мм
