Systeme Electric

Motor protection circuit breaker GM3P 30-40A comb. trip rot. handle screw clamp SE GM3P40 Systeme Electric

SKU: GM3P40 ETIM: EC000074

37,607 ₽

Description Specifications Reviews

Height 139 мм

Depth 136 мм

Overload protection device setting range to 40 А

Setting range of overload protection device from 30 А

Number of poles 3

Design Built-in fixed-mounted device

Rated power in AC-3 mode, 230 V 7.5 кВт

Rated power at AC-3, 400 V 18.5 кВт

Rated ultimate breaking capacity Icu at 400V AC 50 кА

Rated voltage at 690 В

Rated voltage from 690 В

Rated continuous current Iu 40 А

With overheating protection Yes

Tripping system Thermomagnetic

With built-in auxiliary switch No

With built-in undervoltage release No

IP protection rating IP20

Main electrical circuit connection type Screw connection

Control element type Rotary switch

Phase failure sensitive Yes

Width 55 мм
