TOKOV ELECTRIC
Residual Current Device (RCD) 2p (1P+N) 63A 100mA type AC 6kA PRIZMA TOKOV ELECTRIC TKE-PZ60-RCDM-2-63-100-AC
SKU: TKE-PZ60-RCDM-2-63-100-AC
ETIM: EC000003
1,868 ₽
Analogues by specifications
Stock by warehouse
No description available
Additional equipment possible
No
Mounting installation depth
50 мм
Number of poles
2
Rated ultimate breaking capacity (Icw)
6 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
400 В
Rated current
63 А
Rated leakage current
100 мА
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25 град.C
With short-time delayed tripping
No
With interlock device
No
Selective protection
No
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
16 кв.мм
Solid conductor cross-section from
1 кв.мм
Mounting method
DIN rail
IP protection rating
IP20
Residual current type
Alternating current (AC)
Frequency (Hz)
50 Hz
Width in modular units
2
