Residual current device (RCD) 4p 100A 100mA type A OptiDin DМ63-43100 A УХЛ4 КЭАЗ 254332
SKU: 254332
ETIM: EC000003
4,487 ₽
Get back 44 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Additional equipment possible
No
Mounting installation depth
77.5 мм
Number of poles
4
Rated breaking capacity in accordance with EN 60898
0 кА
Rated ultimate breaking capacity (Icw)
0 кА
Rated impulse voltage
4 кВ
Rated voltage
400 В
Rated insulation voltage Ui
400 В
Rated current
100 А
Rated leakage current
.1 мА
Ambient operating temperature to
40 град.C
Ambient operating temperature from
-25 град.C
With short-time delayed tripping
No
With interlock device
No
Selective protection
No
Flexible stranded conductor cross-section up to
35 кв.мм
Stranded flexible conductor cross-section from
1 кв.мм
Solid conductor cross-section to
35 кв.мм
Solid conductor cross-section from
1 кв.мм
Mounting method
DIN rail
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
A
Resistance to current surges
4 кА
Frequency (Hz)
50/60 Hz
Width in modular units
4
