EKF
Residual current circuit breaker VD-100N 2P 32A 10mA type AC electro-mechanical 6kA PROXIMA EKF E1026M3210
SKU: E1026M3210
ETIM: EC000003
2,001 ₽
Get back 20 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Additional equipment possible
No
Mounting installation depth
72 мм
Number of poles
2
Rated impulse voltage
4 кВ
Rated voltage
230 В
Rated insulation voltage Ui
660 В
Rated current
32 А
Rated leakage current
0.01 мА
Ambient operating temperature to
55 град.C
Ambient operating temperature from
-40...55 град.C
With short-time delayed tripping
No
With interlock device
No
Selective protection
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
1...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1...25 кв.мм
Mounting method
DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
6 кА
Frequency (Hz)
50 Hz
Width in modular units
2
